It is mainly used in high-rise civil buildings, entertainment places and many construction projects with high safety requirements. It plays the role of not cutting off the power supply in fire, but also achieving the purpose of safety protection
|
Mark |
GB |
JIS |
ASTM |
||||||||
|
TU0、TU1、TU2、T2 |
C1020、C1100 |
C10200、C10300、C10910、C11000 |
|||||||||
|
Executive standard |
GB/T2059、JISH3100、ASTMB152 |
||||||||||
|
Main application |
It is mainly used in high-rise civil buildings, entertainment places and many construction projects with high safety requirements. It plays the role of not cutting off the power supply in fire, but also achieving the purpose of safety protection |
||||||||||
|
Thickness range (mm) |
|
0.09-0.15 |
0.15-0.3 |
0.3-0.6 |
0.6-1.2 |
1.2-2.0 |
|||||
|
tolerance |
±0.008 |
±0.010 |
±0.015 |
±0.025 |
±0.035 |
||||||
|
Width range (mm) |
|
30-400 |
45-400 |
50-400 |
80-400 |
||||||
|
tolerance |
≤400 ±0.1 |
||||||||||
|
Strength of extense (MPa) |
≥200 |
≥230 |
|||||||||
|
Ductility (%) |
≥20 |
≥30 |
|||||||||
|
Vickers hardness（HV） |
50-75 |
||||||||||
|
Electric conductivity (%IACS) |
≥99 |
||||||||||
Fullway Technology Co., Ltd. was founded in 2004, As a professional China Copper Strip for Fire-proof Cable manufacturers and wholesale Copper Strip for Fire-proof Cable suppliers, our products widely used in electronics, computers, communications, electric power, automotive, railway, aerospace and other fields.
