Clad Copper strip

It is mainly used to manufacture outer covering cladding layer of copper-clad aluminium conductor. As the inner conductor core wire of RF cable, it transfers signal.

Inquire Now

product details


Mark		GB		JIS		ASTM
		TU1、TU2、T2		C1020、C1100		C10200、C10300、 C11000
Executive standard		GB/T 26015-2010、JISH3100、ASTMB152
Main Application		Mainly applicable to copper-clad aluminum wires, copper-clad steel wires and other related fields.
Thickness range mm	Thickness	≥0.2-0.5	≥0.5-0.8		≥0.8-1.2		≥1.2-1.5
	Tolerance	±0.006	±0.008		±0.010		±0.015
Width range mm	Width	30-400（Custom）
	Tolerance	±0.1
Temper		O60
Strength of extense MPa		≥230
Ductility %		≥30
Vickers hardness HV		50-65
Electric conductivity %IACS		≥99

Product Usage
